KV Cache Optimization: Scaling to Million-Token Contexts

The KV (Key-Value) cache is the memory bottleneck for long-context LLM inference. This post explores techniques to reduce KV cache memory while maintaining model quality.

The KV Cache Problem

For each generated token, we cache Keys and Values from all previous tokens:

Memory = 2 × layers × heads × seq_len × head_dim × bytes

For LLaMA-70B at 100K context:
= 2 × 80 × 64 × 100,000 × 128 × 2 (FP16)
= 262 GB just for KV cache!

Optimization Techniques

1. Multi-Query Attention (MQA)

Share K,V across all query heads:

Standard MHA:  Q[H,D] × K[H,D] × V[H,D]
MQA:           Q[H,D] × K[1,D] × V[1,D]

Memory reduction: H× (e.g., 64×)

2. Grouped-Query Attention (GQA)

Compromise between MHA and MQA:

class GroupedQueryAttention(nn.Module):
    def __init__(self, d_model, n_heads, n_kv_heads):
        self.n_heads = n_heads
        self.n_kv_heads = n_kv_heads
        self.head_dim = d_model // n_heads

        self.q_proj = nn.Linear(d_model, n_heads * self.head_dim)
        self.k_proj = nn.Linear(d_model, n_kv_heads * self.head_dim)
        self.v_proj = nn.Linear(d_model, n_kv_heads * self.head_dim)

    def forward(self, x, kv_cache=None):
        q = self.q_proj(x).view(B, L, self.n_heads, self.head_dim)
        k = self.k_proj(x).view(B, L, self.n_kv_heads, self.head_dim)
        v = self.v_proj(x).view(B, L, self.n_kv_heads, self.head_dim)

        # Repeat KV heads to match Q heads
        k = k.repeat_interleave(self.n_heads // self.n_kv_heads, dim=2)
        v = v.repeat_interleave(self.n_heads // self.n_kv_heads, dim=2)

3. KV Cache Quantization

Reduce precision of cached values:

def quantize_kv_cache(k, v, bits=4):
    # Per-channel quantization
    k_min, k_max = k.min(dim=-1), k.max(dim=-1)
    v_min, v_max = v.min(dim=-1), v.max(dim=-1)

    # Quantize
    k_quant = quantize(k, k_min, k_max, bits)
    v_quant = quantize(v, v_min, v_max, bits)

    return k_quant, v_quant, (k_min, k_max, v_min, v_max)

# FP16 → INT4 = 4× memory reduction

4. Sliding Window Attention

Only attend to recent tokens:

def sliding_window_attention(q, k, v, window_size=4096):
    seq_len = q.shape[1]

    # Create sliding window mask
    mask = torch.ones(seq_len, seq_len, dtype=torch.bool)
    for i in range(seq_len):
        mask[i, max(0, i-window_size):i+1] = False

    # Apply mask (set masked positions to -inf)
    attn_weights = q @ k.T / math.sqrt(d)
    attn_weights.masked_fill_(mask, float('-inf'))

    return softmax(attn_weights) @ v

5. StreamingLLM

Keep attention sinks + recent tokens:

def streaming_attention(q, k, v, n_sink=4, n_recent=4096):
    """
    Keep first n_sink tokens (attention sinks) +
    most recent n_recent tokens
    """
    seq_len = k.shape[1]

    if seq_len <= n_sink + n_recent:
        return standard_attention(q, k, v)

    # Select sink + recent tokens
    keep_indices = list(range(n_sink)) + list(range(seq_len - n_recent, seq_len))

    k_selected = k[:, keep_indices]
    v_selected = v[:, keep_indices]

    return standard_attention(q, k_selected, v_selected)

6. Token Dropping / Pruning

Remove less important tokens from cache:

def prune_kv_cache(k, v, importance_scores, keep_ratio=0.5):
    """Remove lowest-importance tokens"""
    n_keep = int(k.shape[1] * keep_ratio)

    # Keep top-k by importance
    _, indices = importance_scores.topk(n_keep)
    indices = indices.sort().values

    k_pruned = k[:, indices]
    v_pruned = v[:, indices]

    return k_pruned, v_pruned

7. Paged Attention (vLLM)

Manage KV cache like virtual memory:

Physical KV blocks    Logical sequence
┌────┬────┬────┐     ┌────┬────┬────┬────┐
│ B0 │ B1 │ B2 │ ←── │ S0 │ S1 │ S2 │ S3 │
└────┴────┴────┘     └────┴────┴────┴────┘
                           ↓
                     Page table maps
                     logical → physical

Benefits:

No memory fragmentation
Efficient batch scheduling
Memory sharing across sequences

Comparison

Technique	Memory Reduction	Quality Impact	Complexity
MQA	64×	Moderate	Architecture change
GQA (8 groups)	8×	Minimal	Architecture change
INT4 Quantization	4×	Minimal	Easy
Sliding Window	Bounded	Task-dependent	Easy
StreamingLLM	Bounded	Minimal	Easy
Paged Attention	No reduction	None	Complex

Combining Techniques

Modern systems combine multiple approaches:

LLaMA-3-70B Long Context:
- GQA (8 KV heads vs 64 Q heads): 8× reduction
- Sliding window (128K): Bounded memory
- Paged attention: No fragmentation
- INT8 KV cache: Additional 2× reduction

Result: 1M+ tokens feasible on single GPU

References

The KV cache is where the rubber meets the road for long-context LLMs—these optimizations make million-token contexts practical.
