Mechanistic Interpretability: Reverse-Engineering Neural Networks

Mechanistic interpretability aims to understand neural networks by identifying the specific algorithms and circuits they implement—moving beyond behavioral analysis to truly understand how models work internally.

The Core Challenge

Neural networks are often called "black boxes," but mechanistic interpretability researchers argue they're more like "compiled code"—difficult to read but not fundamentally unknowable.

Traditional ML:    Input → [Black Box] → Output
                           ↓
Mechanistic:       Input → [Circuits, Features, Algorithms] → Output
                           ↓
                   We can understand each component

Key Concepts

Features and Superposition

Features: The fundamental units of representation in neural networks. A feature might represent "the concept of dogs" or "the presence of curves."

Superposition: Networks represent more features than they have dimensions by encoding multiple features in overlapping patterns:

$\text{Features} \gg \text{Dimensions}$

This is possible because not all features activate simultaneously, allowing efficient "compressed" representations.

Circuits

Circuits are subgraphs of the network that implement specific computations:

Example: Indirect Object Identification Circuit

"When Mary and John went to the store, John gave a drink to"
                                                          ↓
[Name Mover Heads] ← [S-Inhibition Heads] ← [Duplicate Token Heads]
        ↓                    ↓                      ↓
   Copy "Mary"         Inhibit "John"         Detect repetition
        ↓
   Output: "Mary"

Attention Head Functions

Specific attention heads perform identifiable functions:

Head Type	Function	Example
Induction Heads	Pattern completion	[A][B]...[A] → [B]
Name Mover Heads	Copy names to output	"John said" → "John"
Negative Heads	Suppress incorrect outputs	Reduce probability of wrong tokens
Backup Heads	Redundancy for important functions	Parallel circuits

Research Methodology

1. Activation Patching

Replace activations from one input with another to identify causal importance:

def activation_patching(model, clean_input, corrupted_input, layer, position):
    # Run model on both inputs
    clean_activations = model.get_activations(clean_input, layer)
    corrupted_activations = model.get_activations(corrupted_input, layer)

    # Patch: use clean activation at specific position in corrupted run
    patched_activations = corrupted_activations.clone()
    patched_activations[position] = clean_activations[position]

    # Measure effect on output
    return model.forward_with_activations(corrupted_input, patched_activations, layer)

2. Probing

Train simple classifiers on intermediate activations:

class LinearProbe(nn.Module):
    def __init__(self, hidden_dim, num_classes):
        super().__init__()
        self.linear = nn.Linear(hidden_dim, num_classes)

    def forward(self, activations):
        return self.linear(activations)

# Train probe to predict if activation represents "positive sentiment"
probe = LinearProbe(768, 2)
# If probe achieves high accuracy, the feature is linearly represented

3. Sparse Autoencoders

Decompose activations into interpretable features:

class SparseAutoencoder(nn.Module):
    def __init__(self, d_model, n_features, sparsity_coef=1e-3):
        super().__init__()
        self.encoder = nn.Linear(d_model, n_features)
        self.decoder = nn.Linear(n_features, d_model)
        self.sparsity_coef = sparsity_coef

    def forward(self, x):
        # Encode to sparse features
        features = F.relu(self.encoder(x))
        # Decode back
        reconstruction = self.decoder(features)

        # Loss = reconstruction + sparsity
        recon_loss = F.mse_loss(reconstruction, x)
        sparsity_loss = self.sparsity_coef * features.abs().mean()

        return reconstruction, features, recon_loss + sparsity_loss

Major Findings

Anthropic's Research

Features are interpretable: Sparse autoencoders find features corresponding to concepts like "Golden Gate Bridge," "deception," "code errors"
Feature steering: Activating specific features changes model behavior predictably
Safety-relevant features: Features exist for concepts like "harmful content," "deception," "sycophancy"

OpenAI's Research

Superposition is real: GPT-2 uses superposition extensively, especially in early layers
Circuits are modular: Specific circuits handle specific tasks (e.g., modular arithmetic)
Scaling affects interpretability: Larger models may be more interpretable due to less superposition pressure

Applications

AI Safety

1. Identify deception features → Monitor for activation
2. Find refusal circuits → Ensure robustness to jailbreaks
3. Locate knowledge → Verify factual grounding
4. Map goal representations → Align with human values

Model Editing

# If we find the "Eiffel Tower → Paris" circuit:
def edit_knowledge(model, old_fact, new_fact):
    # Locate relevant parameters
    circuit = find_circuit(model, old_fact)

    # Modify weights to encode new fact
    edit_weights(circuit, new_fact)

    # Verify edit is localized
    assert other_knowledge_preserved(model)

Debugging

Understanding why a model fails enables targeted fixes rather than brute-force retraining.

Challenges

Scale: Models have billions of parameters; manual analysis doesn't scale
Polysemanticity: Single neurons often represent multiple concepts
Distributed representations: Important computations span many components
Validation: How do we verify our interpretations are correct?

Tools & Resources

TransformerLens: Library for mechanistic interpretability
Neuronpedia: Database of interpretable features
Circuitsvis: Visualization tools
SAELens: Sparse autoencoder training

Future Directions

Automated interpretability: Using AI to interpret AI
Scaling to frontier models: Interpreting GPT-4/Claude-scale systems
Real-time monitoring: Interpretability during inference
Formal verification: Mathematical proofs about model behavior

References

Mechanistic interpretability may be our best hope for truly understanding—and safely deploying—advanced AI systems.
